TRIE-Series
Here is our list of Internally Driven Electro-Mechanical components.| Picture | Part Number (Click for spec Sheet) | Rated Voltage | Operating Voltage | Frequency | Sound Pressure level | Max Input Current | Mounting Type | Termination |
|---|---|---|---|---|---|---|---|---|
 | TRIE-1201P(G) | 1.5V | 1.0 ~ 2V | 2300Hz | 80dB @ 10cm | 20mA | Through-Hole | Pins |
| TRIE-1203P(G) | 3V | 2 ~ 5V | 2300Hz | 80dB @ 10cm | 30mA | Through-Hole | Pins | |
| TRIE-1205P(G) | 5V | 4 ~ 8V | 2300Hz | 85dB @ 10cm | 30mA | Through-Hole | Pins | |
| TRIE-1212P(G) | 12V | 8 ~ 15V | 2300Hz | 85dB @ 10cm | 30mA | Through-Hole | Pins | |
| TRIE-1605P(G) | 5V | 4 ~ 8V | 2300Hz | 85dB @ 10cm | 30mA | Through-Hole | Pins | |
| TRIE-1612P(G) | 12V | 8 ~ 15V | 2300Hz | 85dB @ 10cm | 30mA | Through-Hole | Pins | |
| TRIE-2312L(G) | 12V | 9 ~ 15V | 400Hz | 75dB @ 20cm | 25mA | Flange | Wire Leads | |
| TRIE-2324L(G) | 24V | 15 ~ 27V | 400Hz | 75dB @ 20cm | 25mA | Flange | Wire Leads | |
| TRIE-2340P | 6V | 4 ~ 8V | 400Hz | 75dB @ 20cm | 25mA | Through-Hole | Pins | |
| TRIE-2341P | 12V | 9 ~ 15V | 400Hz | 75dB @ 20cm | 25mA | Through-Hole | Pins | |
| TRIE-2606F | 6V | 4 ~ 8V | 400Hz | 95dB @ 10cm | 35mA | Flange | Quick-Connect | |
| TRIE-2606L(G) | 6V | 4 ~ 8V | 400Hz | 95dB @ 10cm | 30mA | Flange | Wire Leads | |
| TRIE-2606P(G) | 6V | 4 ~ 8V | 400Hz | 95dB @ 10cm | 35mA | Through-Hole | Pins | |
| TRIE-2612F | 12V | 1 ~ 2V | 400Hz | 95dB @ 10cm | 35mA | Flange | Quick-Connect | |
| TRIE-2612L(G) | 12V | 9 ~ 15V | 400Hz | 95dB @ 10cm | 30mA | Flange | Wire Leads | |
| TRIE-2612P4HS | 12V | 8 ~ 16V | 400Hz | 95dB @ 10cm | 45mA | Through-Hole | Pins | |
| TRIE-2624F | 24V | 20 ~ 28V | 400Hz | 95dB @ 10cm | 35mA | Flange | Quick-Connect | |
| TRIE-2624L | 24V | 20 ~ 28V | 400Hz | 95dB @ 10cm | 30mA | Flange | Wire Leads | |
| TRIE-2624P4H | 24V | 20 ~ 28V | 400Hz | 95dB @ 10cm | 35mA | Through-Hole | Pins |
